2025 Super Duty^® F-450^® XL

Build & Price

Key Features

6.7L Power Stroke^® V8 Turbo Diesel Engine

The available 6.7L Power Stroke V8 Turbo Diesel engine has a 36,000-psi fuel-injection system. It also features forged-steel pistons, which make 475 hp at 2,600 rpm and available 1,050 lb.-ft. of torque at 1,600 rpm. * Finally, the engine features an electric-actuated variable-geometry turbocharger that improves throttle response.

*Horsepower and torque are independent attributes and may not be achieved simultaneously.

Close-up of a man using the box side step

Integrated Box Side Steps and Rear Corner Bumper Steps

To combat the box side hang over while loading and retrieving items from the truck bed, we fitted work-boot-size steps molded into the box side and rear corner steps integrated into the bumper. Molded hand cups on the top of the box help so you can reach into the bed easily and comfortably.

SYNC^® 4 With 8-Inch LCD Touchscreen

Standard SYNC^® 4 Technology²⁷ helps keep you connected to the people and places that matter to you most — and to some of the apps you use most often.

Exterior Features

Appearance

Standard

Bumpers, front and rear - black painted
Door Handles - black
Quad beam halogen jewel effect
AutoLamp (Auto On/Off Headlamps)
Center High-mounted Stop Lamp (LED on King Ranch^® and Platinum)
LED Roof Marker/Clearance Lamps (F-350^® DRW/F-450^®)
Grille - Black MIC
Mirrors - Manual Telescoping/Folding Trailer Tow with Manual Glass
Mirrors - Manual Telescoping/Folding Trailer Tow with Power Heated Glass, Heated convex spotter mirror, integrated clearance lamps/turn signals
Tailgate - Removable w/key lock
Tailgate - Tailgate, Power Lock
Tow hooks – (2) front, black
Center High-mounted Stop Lamp (CHMSL)

Optional

Bumpers, front and rear - chrome
Platform Running Boards
Halogen fog lamps
Automatic High Beam
LED Box Lighting (incl. LED Center High-Mounted Stop Lamp (CHMSL))
Grille - Bright Chrome
Tailgate - Tailgate Step
Tie-down hooks – pickup box

Exterior

Optional

Pro Trailer Hitch Assist

Protection

Standard

Splash Guards - Front F-450^®
Daytime Running Lamps

Optional

Tough Bed^® spray-in bedliner
Skid Plates (4x4)
Bed Mat
LED Warning Strobes (360-Degree Dual Beacon) - Amber
LED Warning Strobes (360-Degree Dual Beacon) - Amber/White
360-Degree Trailer Camera
Individual Trailer TPMS
Individual Trailer TPMS/Customer-Placed Trailer Camera
Tonneau Pickup Box Cover - Soft Folding
Tonneau Pickup Box Cover - Hard Folding
Tonneau Pickup Box Cover - Retractable
Retractable Bed Side-Step
Aluminum Crossbed Toolbox by Weather Guard (Defender Series)
Premium Aluminum Crossbed Toolbox by Weather Guard

Windows & Glass

Standard

Glass – rear, solar tinted
Window - rear, fixed

Optional

Window - rear, power sliding with defrost privacy glass (SuperCab and Crew Cab)

Interior Features

Climate

Standard

Air Conditioning – Manual Temperature Control

Optional

Rapid-Heat Supplemental Cab Heater (Diesel Only)

Comfort and Convenience

Standard

Cruise control
Dash-top tray
Floor Covering - black vinyl
Carpet Delete
Grab handles - driver and front passenger and roof ride handles; front passenger (also over rear doors with Crew Cab)
Headliner – color-coordinated cloth
4.2" LCD Productivity Screen
Instrumentation – Multi-function switch message center
Power Equipment - accessory delay
Power Equipment - Power door locks and windows
Two (2) Powerpoint in instrument panel
Trailer Sway Control and Hill Start Assist
Rear View Camera—Tailgate Mounted
11.5" Day/Night
Steering Wheel - Audio Controls
Steering wheel – black urethane with tilt and telescoping steering wheel/column; includes three (3) button message control
Instrument panel – Color-coordinated w/ glove box, 4 air registers w/ positive shut off, powerpoint
Storage - Front Arm Rest Storage (40/20/40 Seating)
Sun visors – Color-coordinated vinyl, driver w/ pocket, passenger w/ uncovered mirror
Tilt/Telescoping steering wheel
Windshield wipers - intermittent
FordPass^® Connect with 5G Wi-Fi Hotspot connects up to 10 devices
Ford Telematics^™
Ford Data Services^™

Optional

Color-coordinated carpet and carpeted floor mats (includes rear mats on SuperCab & Crew Cab)
Floor Mats—All-weather
120-volt/400-watt dash-mounted outlet
Pro Power Onboard – 2KW
Reverse Brake Assist with Rear Parking Sensors
BLIS^® with Cross-Traffic Alert and Trailer Coverage (BLIS^® sensor in taillamp)
Pre-Collision Assist with Automatic Emergency Braking (AEB) and Forward Collision Warning
Reverse Sensing System
Remote Start System
Upfitter Switches, six (6) located in overhead console
Exterior Backup Alarm
Vehicle Integration System 2.0
360-Degree Camera
Wired Aux Trailer Camera Compatibility
Trailer Reverse Guidance

Entertainment Systems

Standard

Audio – AM/FM stereo/MP3 Player (four (4))
SYNC^® 4 with 8" LCD Capacitive Touchscreen with Swipe Capability

Seating

Standard

Seats - Front, HD Vinyl 40/20/40 Split Bench
Seats - Medium Dark Slate
Seats - Front, Manual Lumbar Support, Driver Side
Front center-seat-integrated restraints (SIR)
Two-way adjustable driver/passenger headrests
Seats - Rear, Vinyl 60/40 Fold-Up Bench Seat (SuperCab)
60/40 bench w/flip-up/fold-down w/two (2) outboard head restraints and a center head restraint (Crew Cab)
Power Equipment Group

Optional

Seats - Front, Cloth 40/20/40 Split Bench
Seats - Front, Vinyl 40/mini-console/40 (Regular Cab)
Seats - Front, Cloth 40/Mini-console/40 (Regular Cab)
Interior Work Surface (req. 40/20/40 seat)

Packages

Power and Handling

Handling

Standard

Alternator - 190-amp 6.7L
Mono-beam Wide Track Front Suspension with Extended axle (F-450^®)
Rear – 4.30 Limited-Slip (F-450^®)
Brakes – Four-wheel disc Anti-lock Brake System (ABS)
AdvanceTrac^® with RSC^® (Roll Stability Control^™) and Trailer Sway Control
Trailer Sway Control
Engine Idle Shutdown – Programmable
29 Gallon Fuel Tank (Diesel Engine) – 142" (Regular Cab) & 148" (SuperCab 6.75 ft. box) Wheelbase
48 Gallon Fuel Tank (Diesel Engine) – 176" (Crew Cab 8 ft. box) Wheelbase
Shock absorbers – heavy-duty gas
Stabilizer bar – front
Stationary Elevated Idle Control (SEIC)
Steering damper
Intelligent Oil-Life Monitor^® (6.7L Power Stroke^® Diesel engine)
Trailer Hitch Receiver – 3" Built Ford Tough^® Trailer Hitch Receiver
4-Wheel-Drive System with auto/manual locking hubs
Electronic-Shift-On-the-Fly (ESOF) (4x4 only)

Optional

Dual Battery (Gas only)
Alternator - 250-amp 6.7L
Alternators - Dual 410-amp total 6.7L
Engine block heater
Trailer Brake Controller
Transmission Power Take-off Provision (PTO)
Gooseneck Dual Hitch Kit (F-450^® only)
5th Wheel Hitch Kit - 32,500 lbs. DRW

Power

Standard

Engine - 6.7L Power Stroke^® V8 Turbo Diesel
TorqShift^® 10-speed Automatic with Selectable Drive Modes: Normal, Slippery, Tow/Haul, Eco
Diesel Engine-Exhaust Brake (diesel engine only)

Optional

Engine - 6.7 HO Power Stroke V8 Turbo Diesel

Wheels & Tires

Standard

Wheels - 19.5-inch Forged Polished Aluminum
225/70Rx19.5G BSW A/S (6)
Spare tire, wheel & carrier
Jack - 4-ton, hydraulic (DRW)

Safety

Specifications

Highlights

Fuel Capacity	29 gallons
	34 gallons
	48 gallons
Drive Type	4x2
	4x4
Available Engines	6.8L N/A V8 Gas
	7.3L N/A V8 Gas
	6.7L Power Stroke^® V8 Turbo Diesel
	6.7L HO Power Stroke^® V8 Turbo Diesel
	HP = 405 @ 5,000 rpm \| TQ = 445 @ 4,000 rpm (6.8L Gas V8)
	HP = 430 @ 5,500 rpm \| TQ = 485 @ 4,000 rpm (7.3L Gas V8)
	HP = 475 @ 2,600 rpm \| TQ = 1,050 @ 1,600 rpm (6.7L Power Stroke^® Turbo Diesel)
	HP = 500 @ 2,600 rpm \| TQ = 1,200 @ 1,600 rpm (6.7L HO Power Stroke^® Turbo Diesel)
Transmission	TorqShift^®-G 10-speed SelectShift Automatic^® with Selectable Drive Modes
	TorqShift^® 10-speed SelectShift Automatic^® with Selectable Drive Modes
Wheelbase	141.4" (Regular Cab)
	147.8" (SWB SuperCab); 164.1" (LWB SuperCab)
	159.7" (SWB Crew Cab); 175.9" (LWB Crew Cab)
Warranty	Bumper to Bumper: 3 years / 36,000 miles
	Powertrain: 5 years / 60,000 miles; Diesel: 5 years / 100,000 miles
	Safety Restraint System: 5 years / 60,000 miles
	Corrosion (Perforation only): 5 years / Unlimited miles
	Roadside Assistance Program: 5 years / 60,000 miles

Exterior

Exterior Dimensions
		Regular Cab	Regular Cab	Super Cab	Super Cab	Crew Cab	Crew Cab	Crew Cab	Crew Cab
		8 ft. Box	8 ft. Box	LWB - 8 ft. Box	LWB - 8 ft. Box	SWB - 6.75 ft. Box	SWB - 6.75 ft. Box	LWB - 8 ft. Box	LWB - 8 ft. Box
		4x2	4x4	4x2	4x4	4x2	4x4	4x2	4x4
Wheelbase (in)		141.4	141.5	164.1	164.1	159.7	159.7	175.9	175.9
Length - overall (in)		231.8	231.8	254.4	254.4	250.0	250.0	266.2	266.2
Height - F-250^® SRW (w/o options) (in)		78.9	81.4	79.1	81.5	79.3	81.6	79.0	81.4
Height - F-350^® SRW (w/o options) (in)		78.8	81.3	79.0	81.3	79.2	81.4	78.9	81.2
Height - F-350^® DRW (w/o options) (in)		79.4	81.3	79.1	81.4	-	-	79.5	81.5
Height - F-450^® DRW (w/o options) (in)		82.0	82.0	-	-	-	-	81.3	82.1
Width - SRW without mirrors (in)		80	80	80	80	80	80	80	80
Width - DRW without mirrors (in)		96	96	96	96	-	-	96	96
Width - SRW/DRW with standard mirrors (in)		105.9	105.9	105.9	105.9	105.9	105.9	105.9	105.9
Track - front - F-250^® SRW (in)		69.5	69.5	69.5	69.5	69.5	69.5	69.5	69.5
Track - front - F-350^® SRW (in)		69.5	69.5	69.5	69.5	69.5	69.5	69.5	69.5
Track - front - F-350^® DRW (in)		69.5	69.5	69.5	69.5	69.5	69.5	69.5	69.5
Track - front - F-450^® DRW (in)		77	77	-	-	-	-	74.8	74.8
Track - rear - F-250^® SRW (in)		67.2	67.2	67.2	67.2	67.2	67.2	67.2	67.2
Track - rear - F-350^® SRW (in)		67.2	67.2	67.2	67.2	67.2	67.2	67.2	67.2
Track - rear - F-350^® DRW (in)		74	74	74	74	-	-	74	74
Track - rear - F-450^® DRW (in)		74	74	-	-	-	-	74	74
Minimum running ground clearance - F-250^® SRW (in)		9.7	9.4	10.2	9.7	9.9	9.2	10.2	9.5
Minimum running ground clearance - F-350^® SRW (in)		9.7	9.3	10.2	10.6	10.1	9.1	10.2	9.4
Minimum running ground clearance - F-350^® DRW (in)		9.9	9.2	10.2	9.4	-	-	10.2	9.8
Minimum running ground clearance - F-450^® DRW (in)		8.6	8.6	-	-	-	-	10.3	10.3
Overhang - front (in)		38.2	38.3	38.2	38.3	38.2	38.3	38.2	38.3
Overhang - rear (in)		52.2	50.0	52.2	50.0	52.2	50.0	52.2	50.0
Angle of departure - F-250^® SRW (degrees)		19.7	21.3	18.7	20.8	19.3	21.1	18.8	20.8
Angle of departure - F-350^® SRW (degrees)		19.4	21.1	18.5	20.6	19	20.9	18.7	20.6
Angle of departure - F-350^® DRW (degrees)		20.7	21.5	18.7	20.9	-	-	20	20.9
Angle of departure - F-450^® DRW (degrees)		21.6	21.5	-	-	-	-	20.8	20.8
Ramp breakover angle - F-250^® SRW (degrees)		20.3	24.7	20.7	21.9	18.5	21.9	17.3	20.5
Ramp breakover angle - F-350^® SRW (degrees)		19.4	21.1	18.3	21.7	18.4	21.7	17.2	20.3
Ramp breakover angle - F-350^® DRW (degrees)		20.7	21.5	22.7	21.8	-	-	17.4	20.7
Ramp breakover angle - F-450^® DRW (degrees)		25.4	25.4	-	-	-	-	20.7	20.7
Angle of approach - F-250^® SRW (degrees)		16.7	15.8	21.8	27.6	21.2	26.7	21.7	27.3
Angle of approach - F-350^® SRW (degrees)		16.6	15.7	17.4	16.2	21.5	26.6	21.8	27.2
Angle of approach - F-350^® DRW (degrees)		20.7	21.5	17.8	17.4	-	-	21.7	27.7
Angle of approach - F-450^® DRW (degrees)		18.5	18.5	-	-	-	-	26.9	26.9
Open tailgate to Ground - F-250^® SRW (in)		36.5	37.6	35.6	37	35.3	38.1	35.2	36.8
Open tailgate to Ground - F-350^® SRW (in)		36.3	37.4	35.4	36.9	35.3	36.9	35.0	36.6
Open tailgate to Ground - F-350^® DRW (in)		37.3	37.7	35.6	37.1	-	-	36.2	36.9
Open tailgate to Ground - F-450^® DRW (in)		38.3	38.1	-	-	-	-	36.8	36.8
Length - front bumper to back of cab (in)		123.6	123.6	146.2	146.2	158.0	158.0	158.0	158.0

Curb Weights (lbs)		Regular Cab	Regular Cab	Super Cab	Super Cab	Crew Cab	Crew Cab	Crew Cab	Crew Cab
Box Size		8 ft. Box	8 ft. Box	LWB - 8 ft. Box	LWB - 8 ft. Box	SWB - 6.75 ft. Box	SWB - 6.75 ft. Box	LWB - 8 ft. Box	LWB - 8 ft. Box
Drivetrain		4x2	4x4	4x2	4x4	4x2	4x4	4x2	4x4
Base Curb Weight - F-250^® SRW	6.8L	5,697	6,148	6,104	6,504	6,041	6,396	6,264	6,699
Base Curb Weight - F-250^® SRW	6.7L	6,583	6,996	6,999	7,386	6,963	7,331	7,210	7,645
Base Curb Weight - F-250^® SRW	7.3L	5,801	6,232	6,187	6,587	6,142	6,480	6,348	6,783
Base Curb Weight - F-250^® SRW	6.7L HO	6,598	7,011	7,014	7,401	6,978	7,346	7,225	7,660
Base Curb Weight - F-350^® SRW (17" Wheels)	6.8L	-	6,220	6,148	6,628	6,191	6,608	6,417	6,722
Base Curb Weight - F-350^® SRW (17" Wheels)	6.7L	6,553	6,972	6,897	7,372	6,947	7,372	7,184	7,649
Base Curb Weight - F-350^® SRW (17" Wheels)	7.3L	-	6,433	6,361	6,841	6,405	6,821	6,630	6,936
Base Curb Weight - F-350^® SRW (17" Wheels)	6.7L HO	6,568	6,987	6,913	7,388	6,962	7,387	7,199	7,664
Base Curb Weight - F-350^® SRW (18" Wheels A/S)	6.8L	5,854	6,277	6,205	6,633	6,248	6,665	6,474	6,780
Base Curb Weight - F-350^® SRW (18" Wheels A/S)	6.7L	6,610	7,029	6,955	7,377	7,004	7,429	7,241	7,732
Base Curb Weight - F-350^® SRW (18" Wheels A/S)	7.3L	6,068	6,490	6,418	6,846	6,462	6,878	6,687	7,032
Base Curb Weight - F-350^® SRW (18" Wheels A/S)	6.7L HO	6,625	7,044	6,971	7,393	7,019	7,444	7,256	7,692
Base Curb Weight - F-350^® DRW	6.8L	6,206	6,647	6,666	7,080	-	-	6,886	7,392
Base Curb Weight - F-350^® DRW	6.7L	6,992	7,421	7,436	7,852	-	-	7,622	8,133
Base Curb Weight - F-350^® DRW	7.3L	6,314	6,743	6,762	7,176	-	-	6,982	7,388
Base Curb Weight - F-350^® DRW	6.7L HO	7,008	7,436	7,451	7,868	-	-	7,637	8,085
Base Curb Weight - F-450^® DRW	6.7L	7,657	8,053	-	-	-	-	8,312	8,587
Base Curb Weight - F-450^® DRW	6.7L HO	7,673	8,068	-	-	-	-	8,327	8,627

Cargo Box	6.75 ft. Box	8.0 ft. Box
Inside Length (at floor) [in]	81.9	98.1
Inside Height [in]	21.1	21.1
Width Between Wheelhouses [in]	50.5	50.5
Maximum Width (at floor) [in]	66.9	66.9
Cargo Box Volume [cu. ft.]	65.4	78.5

Interior

Interior Dimensions
	Regular Cab	Super Cab	Crew Cab
Front (in)
Head room	40.8	40.8	40.8
Shoulder room	66.7	66.7	66.7
Hip room	62.5	62.5	62.5
Max leg room	43.9	43.9	43.9
Rear (in)
Head room	-	40.3	40.4
Shoulder room	-	65.8	65.9
Hip room	-	64.7	64.7
Leg room	-	33.5	43.6
Volumes (cu. ft.)
Passenger - total	64.7	116.3	131.9
Cargo - behind first row	10.9	30.3	53.4

Cargo Box Dimensions
	SWB - 6.75 ft. Box	LWB - 8 ft. Box
Volume (cu. ft.)	65.4	78.5
Length at floor (in)	81.9	98.1
Length at top of Box (in)	80.3	96.4
Height (in)	21.1	21.1
Width at floor (maximum) (in)	66.9	66.9
Width between wheelhouse (in)	50.5	50.5
Rear opening width (in)	60.5	60.5

SWB = Short Wheelbase (6.75' cargo Box)
LWB = Long Wheelbase (8' cargo Box)

Capacities

Capacities: Passengers and Fuel

		Regular Cab	Super Cab	Crew Cab
Seating capacity		3	6	6
Fuel capacity	6.8L Gas	34 gallon	34 gallon	34 gallon (160" WB), 48 gallon (176" WB)
	7.3L Gas	34 gallon	34 gallon	34 gallon (160" WB), 48 gallon (176" WB)
	6.7L Diesel	29 gallon (142" WB)	29 gallon (148" WB), 34 gallon (164" WB)	34 gallon (160" WB), 48 gallon (176" WB)
	6.7L HO Diesel	29 gallon (142" WB)	29 gallon (148" WB), 34 gallon (164" WB)	34 gallon (160" WB), 48 gallon (176" WB)

Chassis

Chassis Specifications
Front Suspension
Type		Mono beam (narrow front track) with coil springs, shock absorbers, stabilizer bar (F-250^®/F-350^® 4x4) Mono beam (wide front track) with coil springs, shock absorbers, stabilizer bar (F-450^®)

Max. Front GAWR		lbs.
		5,000 lbs. (F-250^®)(4x2)
		5,600 lbs. (F-250^®)(4x4)
		5,000 lbs. (F-350^® SRW)(4x2)
		5,600 lbs. (F-350^® SRW)(4x4)
		5,300 lbs. (F-350^® DRW)(4x2)
		5,600 lbs. (F-350^® DRW)(4x4)
		5,600 lbs. (F-450^® 4x2)
		5,600 lbs. (F-450^® 4x4)
Front Springs		Coil
Shock absorbers		Heavy-duty gas
Stabilizer bar		Standard
Rear Suspension
Type		Solid axle
Max. Rear GAWR		6,340 lbs. (F-250^®4x2)
		6,340 lbs. (F-250^® 4x4)
		7,230 lbs. (F-350^® SRW 4x2)
		6,780 lbs. (F-350^® SRW 4x4)
		10,300 lbs. (F-350^® DRW 4x2)
		9,900 lbs. (F-350^® DRW 4x4)
		9,900 lbs. (F-450^® DRW 4x2)
		9,900 lbs. (F-450^® DRW 4x4)
Rear Springs		Leaf
Shock absorbers		Heavy-duty gas
Stabilizer bar		Standard on DRW pickup; optional in select packages on SRW pickup
Steering
Assist		Power Hydraulic
Brakes
Type		4-wheel vented-disc ABS (standard)
Front (rotor diameter)		14.29" (363 mm) (F-250^®/F-350^®)
		15.39" (391 mm) (F-450^®)
Rear (rotor diameter)		14.29" (363 mm) (F-250^®/F-350^®)
		15.75" (400 mm) (F-450^®)
Wheels
Type		Steel or aluminum
Size		17", 18" or 20" (F-250^®/F-350^®)
		17" DRW (F-350^®)
		19.5" DRW (F-450^®)
Number of studs		8 (F-250^®, F-350^®)
		10 (F-450^®)
Bolt-circle diameter		6.69" (170 mm) SRW
		7.87" (200 mm) F-350^® DRW
		8.86" (225 mm) F-450^® DRW

Engine

Engine Specifications
Name	7.3L 2V DEVCT NA PFI V8 Gas	6.8L V8 Gas	6.7L Power Stroke^® V8 Turbo Diesel	6.7L HO Power Stroke^® V8 Turbo Diesel
Configuration	90-degree V8, single in-block cams	90-degree V8, single in-block cams	90-degree diesel V8, single turbocharger, in-block cams and overhead valves	90-degree diesel V8, single turbocharger, in-block cams and overhead valves
Fuel injection/delivery	Sequential Electronic	Sequential Electronic	High-Pressure Common-Rail	High-Pressure Common-Rail
Engine control system	Electronic	Electronic	Electronic	Electronic
Induction system	Specially tuned - (n/a non turbo)	Specially tuned - (n/a non turbo)	Variable Geometry Turbocharger; with charge air cooler	Variable Geometry Turbocharger; with charge air cooler
Battery	12-volt; 750-cca/78-amp-hr	12-volt; 650-cca/72-amp-hr	Dual 12V-volt 750CCA 78-AH	Dual 12V-volt 750CCA 78-AH
Standard Alternator	250-amp (XL/XLT/Lariat/King Ranch/Platinum)	160-amp (XL/XLT)	195-amp (XL/XLT)	195-amp (XL/XLT)
		200-amp (Lariat/King Ranch/Platinum)	250-amp (Lariat/King Ranch/Platinum)	250-amp (Lariat/King Ranch/Platinum)
			352-amp (Limited)	352-amp (Limited)
Cooling system	Pressurized series flow	Pressurized series flow	Pressurized series flow	Pressurized series flow
Oil Life Monitor	Oil Life Monitor^®	Oil Life Monitor^®	Intelligent Oil Life Monitor^®	Intelligent Oil Life Monitor^®
Cylinders	8	8	8	8
Cylinder head	Aluminum	Aluminum	Aluminum	Aluminum
Block material	Cast Iron	Cast Iron	Compacted graphite iron	Compacted graphite iron
Valve operation	Push rod/rocker arms	Roller rocker shaft	Push rod/rocker arms	Push rod/rocker arms
Camshaft drive	Silent chain	Silent chain	Gear	Gear
Bore	4.22" (107.2 mm)	4.22"	3.90"	3.90"
Stroke	3.98" (101 mm)	3.68"	4.25"	4.25"
Compression ratio	10.5:1	10.8:1	15.2:1	15.2:1
Horsepower/rpm	430 @ 5,500	405 @ 5,000	475 @ 2,600	500 @ 2,600
Torque lb.-ft./rpm	485 @ 4,000	445 @ 4,000	1,050 @ 1,600	1,200 @ 1,600
Recommended fuel	87 octane (Not e85 compatible)	87 octane (Not e85 compatible)	Ultra-low sulfur diesel/B20	Ultra-low sulfur diesel/B20

Transmission Specifications
Transmission Type	TorqShift^®-G 10-speed Automatic w/ Selectable Drive Modes: Normal, Eco, Slippery Roads, Tow/Haul (6.8L Gas)
Case material	Aluminum
Power Takeoff	Live-drive access on driver side
Gear ratios	1st	4.696:1
	2nd	2.985:1
	3rd	2.146:1
	4th	1.769:1
	5th	1.520:1
	6th	1.275:1
	Reverse	-4.866:1
Transmission Type	TorqShift^® 10-speed SelectShift Automatic^®
Case material	Aluminum
Power Takeoff	Live-drive access on driver side
Gear ratios	First	4.615:1
	Second	2.919:1
	Third	2.132:1
	Fourth	1.773:1
	Fifth	1.519:1
	Sixth	1.277:1
	Seventh	1.1
	Eighth	0.851:1
	Ninth	0.687:1
	Tenth	0.632:1
	Reverse	-4.695:1

Towing

Conventional Towing - Maximum Available Loaded Trailer Weight Ratings
F-250^® Super Duty SRW
Engine (Automatic Transmission)	Axle Ratio	GCWR (lbs.)	Regular Cab 4x2 141.5" WB 8' Box	Regular Cab 4x4 141.5" WB 8' Box	SuperCab 4x2 164.1" WB 8' Box	SuperCab 4x4 164.1" WB 8' Box	Crew Cab 4x2 159.7" WB 6.75' Box	Crew Cab 4x4 159.7" WB 6.75' Box	Crew Cab 4x2 175.9" WB 8' Box	Crew Cab 4x4 175.9" WB 8' Box
6.7L V8 Turbo Diesel	3.31	23,500	16,600	16,200	16,200	15,800	16,200	15,900	15,900	15,500
6.7L V8 Turbo Diesel	3.31	30,000*	18,200	20,000	19,500	22,000	19,500	22,000	19,500	21,900
6.7L V8 Turbo Diesel	3.55	30,000*	18,200	20,000	19,500	22,000	19,500	22,000	19,500	21,900
6.7L V8 H.O. Turbo Diesel	3.55E**	28,300^†	-	-	-	-	-	18,200	-	-
6.7L V8 H.O. Turbo Diesel	3.31	31,000*	18,200	20,000	19,500	22,000	19,500	22,000	19,500	22,000
6.7L V8 H.O. Turbo Diesel	3.55	31,000*	18,200	20,000	19,500	22,000	19,500	22,000	19,500	22,000
6.8L V8 Gas	3.73	21,000	14,800	14,400	14,500	14,100	14,500	14,100	14,300	13,800
6.8L V8 Gas	4.3	23,500	17,300	16,900	17,000	16,600	17,000	16,600	16,800	16,300
7.3L V8 Gas	3.73	23,500	-	16,900	-	16,600	-	16,700	-	16,400
7.3L V8 Gas	3.73E**	24,600	18,200	18,000	-	17,700	18,100	17,800	17,900	17,500
7.3L V8 Gas	4.3	26,000	18,200	18,200	-	18,200	18,200	18,200	18,200	18,200
*Requires F-250 High-Capacity Axle Upgrade Package.
**3.55E and 3.73E are electronic locking rear axles.
^†Tremor^® Off-Road Package.

F-350^® Super Duty SRW
Engine (Automatic Transmission)	Axle Ratio	GCWR (lbs.)	Regular Cab 4x2 141.5" WB 8' Box	Regular Cab 4x4 141.5" WB 8' Box	SuperCab 4x2 164.1" WB 8' Box	SuperCab 4x4 164.1" WB 8' Box	Crew Cab 4x2 159.7" WB 6.75' Box	Crew Cab 4x4 159.7" WB 6.75' Box	Crew Cab 4x2 175.9" WB 8' Box	Crew Cab 4x4 175.9" WB 8' Box
6.7L V8 Turbo Diesel	3.31	31,000	20,000/20,000*	20,000/20,000,*	23,000/23,000*	23,200/23,100,*	23,000/23,000*	23,200/23,100,*	23,000/23,000*	22,900/22,900/22,800*
6.7L V8 Turbo Diesel	3.55	31,000	20,000/20,000*	20,000/20,000,*	23,000/23,000*	23,200/23,100,*	23,000/23,000*	23,200/23,100,*	23,000/23,000*	22,900/22,900/22,800*
6.7L V8 H.O. Turbo Diesel	3.31	31,800	20,000/20,000*	20,000/20,000,*	-	23,900/23,900,*	-	23,900/23,900,*	23,000/23,000*	23,700/23,600,*
6.7L V8 H.O. Turbo Diesel	3.55	31,200^†	-	-	-	-	-	18,200	-	-
6.7L V8 H.O. Turbo Diesel	3.55	35,200	20,000/20,000*	20,000/20,000,*	23,000	24,000/24,000,*	-	24,000/24,000,*	23,000/23,000*	24,600/25,000,*
6.8L V8 Gas	3.73	21,000	14,700*	14,400/14,300,*	14,400/14,400*	14,000/14,000,*	14,400/14,400*	14,000/14,000,*	14,200/14,100*	13,800/13,700,*
6.8L V8 Gas	4.3	24,400	18,100*	17,800/17,700,*	-	17,400/17,400,*	17,800/17,800*	-	17,600/17,500*	17,200/17,100,*
7.3L V8 Gas	3.73	25,200	18,200*	18,200/18,200,*	-	18,000/18,000,*	18,200/18,200*	18,000/18,000/17,900*	18,200/18,100*	17,800/17,800,*
7.3L V8 Gas	4.3	28,600^†	-	-	-	-	-	18,200	-	-
7.3L V8 Gas	4.3	29,000	18,200*	19,500/19,500,*	-	19,500/19,500,*	19,500/19,500*	19,500/19,500,*	19,500/19,500*	19,500/19,500,*
*18" All-Season Tires.
**18" and 20" All-Terrain Tires.
^†Tremor^® Off-Road Package.

F-350^®/F-450^® Super Duty DRW
Engine (Automatic Transmission)	Axle Ratio	GCWR (lbs.)	F-350^® Regular Cab 4x2 141.5" WB 8' Box	F-350^® Regular Cab 4x4 141.5" WB 8' Box	F-350^® Crew Cab 4x2 175.9" WB 8' Box	F-350^® Crew Cab 4x4 175.9" WB 8' Box	F-450^® Regular Cab 4x2 141.5" WB 8' Box	F-450^® Regular Cab 4x4 141.5" WB 8' Box	F-450^® Crew Cab 4x2 175.9" WB 8' Box	F-450^® Crew Cab 4x4 175.9" WB 8' Box
6.7L V8 Turbo Diesel	3.55	40,000	24,800	24,800	27,000	27,000	-	-	-	-
6.7L V8 Turbo Diesel	4.1	43,900	24,800	24,800	27,000	27,000	-	-	-	-
6.7L V8 Turbo Diesel	4.3	43,500	-	-	-	-	-	-	30,000	30,000
6.7L V8 Turbo Diesel	4.3	46,700	-	-	-	-	25,000	25,000	-	-
6.7L V8 H.O. Turbo Diesel	3.55	40,500	24,800	24,800	27,000	27,000	-	-	-	-
6.7L V8 H.O. Turbo Diesel	4.1	45,600	24,800	24,800	28,000	28,000	-	-	-	-
6.7L V8 H.O. Turbo Diesel	4.3	43,500	-	-	-	-	-	-	30,000	30,000
6.7L V8 H.O. Turbo Diesel	4.3	46,700	-	-	-	-	25,000	25,000	-	-
6.7L V8 H.O. Turbo Diesel	4.3	48,000**	-	-	-	-	18,200	-	-	-
6.8L V8 Gas	4.3	25,400	18,700/18,200*	18,300	-	17,700	-	-	-	-
7.3L V8 Gas	3.73	25,700	18,900	18,500	-	17,900	-	-	-	-
7.3L V8 Gas	4.3	29,500	22,000	22,000	-	21,700	-	-	-	-
*Heavy-Duty Payload Package.
**40k Gooseneck Tow Package.

5th-Wheel - Maximum Available Loaded Trailer Weight Ratings
F-250^® Super Duty SRW
Engine (Automatic Transmission)	Axle Ratio	GCWR (lbs.)	Regular Cab 4x2 141.5" WB 8' Box	Regular Cab 4x4 141.5" WB 8' Box	SuperCab 4x2 164.1" WB 8' Box	SuperCab 4x4 164.1" WB 8' Box	SuperCab 4x2 164.1" WB 8' Box	Crew Cab 4x4 159.7" WB 6.75' Box	Crew Cab 4x2 175.9" WB 8' Box	Crew Cab 4x4 175.9" WB 8' Box
6.7L V8 Turbo Diesel	3.31	23,500	16,300	15,900	15,900	14,100	16,000	14,400	15,000	12,200
6.7L V8 Turbo Diesel	3.31	30,000*	22,300	21,700	20,900	20,600	20,900	20,500	20,200	19,400
6.7L V8 Turbo Diesel	3.55	30,000*	22,300	21,700	20,900	20,600	20,900	20,500	20,200	19,400
6.7L V8 H.O. Turbo Diesel	3.55E**	28,300^†	-	-	-	-	-	19,600	-	-
6.7L V8 H.O. Turbo Diesel	3.31	31,000*	22,300	21,700	20,900	20,600	20,900	20,500	20,200	19,800
6.7L V8 H.O. Turbo Diesel	3.55	31,000*	22,300	21,700	20,900	20,600	20,900	20,500	20,200	19,800
6.8L V8 Gas	3.73	21,000	14,800	14,200	14,200	13,800	14,300	13,900	14,000	13,600
6.8L V8 Gas	4.3	23,500	17,300	16,700	16,700	16,300	16,800	16,400	16,500	16,100
7.3L V8 Gas	3.73	23,500	-	16,700	-	16,300	-	16,400	-	16,100
7.3L V8 Gas	3.73E**	24,600	18,200	17,800	-	17,400	17,900	17,500	17,700	17,200
7.3L V8 Gas	4.3	26,000	19,500	19,200	-	18,800	19,300	18,900/18,500^†	19,100	17,800
*Requires F-250 High-Capacity Axle Upgrade Package.
**3.55E and 3.73E are electronic locking rear axles.
^†Tremor^® Off-Road Package.

F-350^® Super Duty SRW
Engine (Automatic Transmission)	Axle Ratio	GCWR (lbs.)	Regular Cab 4x2 141.5" WB 8' Box	Regular Cab 4x4 141.5" WB 8' Box	SuperCab 4x2 164.1" WB 8' Box	SuperCab 4x4 164.1" WB 8' Box	Crew Cab 4x2 159.7" WB 6.75' Box	Crew Cab 4x4 159.7" WB 6.75' Box	Crew Cab 4x2 175.9" WB 8' Box	Crew Cab 4x4 175.9" WB 8' Box
6.7L V8 Turbo Diesel	3.31	31,000	22,100/23,700*	22,000/23,300,*	20,800/23,200*	20,500/22,800/22,900*	20,700/23,300*	20,500/22,700/22,900*	20,200/23,000*	19,900/22,600,*
6.7L V8 Turbo Diesel	3.55	31,000	22,100/23,700*	22,000/23,300,*	20,800/23,200*	20,500/22,800/22,900*	20,700/23,300*	20,500/22,700/22,900*	20,200/23,000*	19,900/22,600,*
6.7L V8 H.O. Turbo Diesel	3.31	31,800	22,100/24,500*	22,000/24,000,*	-	20,500/22,600/23,600*	-	20,500/22,600/23,600*	20,300/23,000*	19,900/22,600/23,400*
6.7L V8 H.O. Turbo Diesel	3.55	31,200^†	-	-	-	-	-	23,000	-	-
6.7L V8 H.O. Turbo Diesel	3.55	35,200	22,100/24,900*	22,000/24,700/27,400*	20,900/23,600*	20,500/22,600/26,300*	-	20,500/22,600/25,900*	20,300/23,000*	19,900/22,600/25,600*
6.8L V8 Gas	3.73	21,000	14,500*	14,100/14,100,*	14,200,14,100*	13,800/13,700,*	14,200/14,100*	13,800/13,700,*	14,000/13,900*	13,600/13,500,*
6.8L V8 Gas	4.3	24,400	17,900*	17,500/17,500,*	-	17,200/17,100,*	17,600/17,500*	-	17,400/17,300*	17,000/16,900,*
7.3L V8 Gas	3.73	25,200	18,500*	18,200/18,100,*	-	17,800/17,700,*	18,200/18,100*	17,800/17,700,*	17,900/17,900*	17,600/17,500,*
7.3L V8 Gas	4.3	28,600^†	-	-	-	-	-	21,100	-	-
7.3L V8 Gas	4.3	29,000	22,300*	22,000/21,900,*	-	21,300/21,500,*	21,100/21,900*	20,900/21,500,*	21,100/21,700*	20,800/21,300,*
*18" All-Season Tires.
**18" and 20" All-Terrain Tires.
^†Tremor^® Off-Road Package.

F-350^®/F-450^® Super Duty DRW
Engine (Automatic Transmission)	Axle Ratio	GCWR (lbs.)	F-350^® Regular Cab 4x2 141.5" WB 8' Box	F-350^® Regular Cab 4x4 141.5" WB 8' Box	F-350^® Crew Cab 4x2 175.9" WB 8' Box	F-350^® Crew Cab 4x4 175.9" WB 8' Box	F-450^® Regular Cab 4x2 141.5" WB 8' Box	F-450^® Regular Cab 4x4 141.5" WB 8' Box	F-450^® Crew Cab 4x2 175.9" WB 8' Box	F-450^® Crew Cab 4x4 175.9" WB 8' Box
6.7L V8 Turbo Diesel	3.55	40,000	32,300	31,900	31,600	31,200	-	-	-	-
6.7L V8 Turbo Diesel	4.1	43,900	35,000	35,000	35,000	35,000	-	-	-	-
6.7L V8 Turbo Diesel	4.3	43,500	-	-	-	-	-	-	34,200	32,000
6.7L V8 Turbo Diesel	4.3	46,700	-	-	-	-	35,000	35,000	-	-
6.7L V8 H.O. Turbo Diesel	3.55	40,500	32,800	32,300	32,100	31,700	-	-	-	-
6.7L V8 H.O. Turbo Diesel	4.1	45,600	35,000	35,000	35,000	34,900	-	-	-	-
6.7L V8 H.O. Turbo Diesel	4.3	43,500	-	-	-	-	-	-	34,100	31,900
6.7L V8 H.O. Turbo Diesel	4.3	46,700	-	-	-	-	35,000	35,000	-	-
6.7L V8 H.O. Turbo Diesel	4.3	48,000**	-	-	-	-	35,000	-	-	-
6.8L V8 Gas	4.3	25,400	18,500/18,700*	18,100	-	17,400	-	-	-	-
7.3L V8 Gas	3.73	25,700	18,700	18,200	-	17,600	-	-	-	-
7.3L V8 Gas	4.3	29,500	22,500	22,000	-	21,400	-	-	-	-
*Heavy-Duty Payload Package.
**40k Gooseneck Tow Package.

Gooseneck Towing - Maximum Available Loaded Trailer Weight Ratings
F-250^® Super Duty SRW
Engine (Automatic Transmission)	Axle Ratio	GCWR (lbs.)	Regular Cab 4x2 141.5" WB 8' Box	Regular Cab 4x4 141.5" WB 8' Box	SuperCab 4x2 164.1" WB 8' Box	SuperCab 4x4 164.1" WB 8' Box	Crew Cab 4x2 159.7" WB 6.75' Box	Crew Cab 4x4 159.7" WB 6.75' Box	Crew Cab 4x2 175.9" WB 8' Box	Crew Cab 4x4 175.9" WB 8' Box
6.7L V8 Turbo Diesel	3.31	23,500	16,500	16,100	16,100	15,100	16,100	15,400	15,900	13,300
6.7L V8 Turbo Diesel	3.31	30,000*	22,900	22,500	22,000	21,600	22,000	21,600	21,200	20,400
6.7L V8 Turbo Diesel	3.55	30,000*	22,900	22,500	22,000	21,600	22,000	21,600	21,200	20,400
6.7L V8 H.O. Turbo Diesel	3.55E**	28,300^†	-	-	-	-	-	20,000	-	-
6.7L V8 H.O. Turbo Diesel	3.31	31,000*	23,000	22,700	22,000	21,600	22,000	21,600	21,200	20,900
6.7L V8 H.O. Turbo Diesel	3.55	31,000*	23,000	22,700	22,000	21,600	22,000	21,600	21,200	20,900
6.8L V8 Gas	3.73	21,000	14,800	14,400	14,400	14,000	14,400	14,100	14,200	13,800
6.8L V8 Gas	4.3	23,500	17,300	16,900	16,900	16,500	16,900	16,600	16,700	16,300
7.3L V8 Gas	3.73	23,500	-	16,900	-	16,500	-	16,600	-	16,300
7.3L V8 Gas	3.73E**	24,600	18,400	18,000	-	17,600	18,000	17,700	17,800	17,400
7.3L V8 Gas	4.3	26,000	19,500	19,400	-	19,000	19,400	19,100/18,500^†	19,200	18,800
*Requires F-250 High-Capacity Axle Upgrade Package.
**3.55E and 3.73E are electronic locking rear axles.
^†Tremor^® Off-Road Package.

F-350^® Super Duty SRW
Engine (Automatic Transmission)	Axle Ratio	GCWR (lbs.)	Regular Cab 4x2 141.5" WB 8' Box	Regular Cab 4x4 141.5" WB 8' Box	SuperCab 4x2 164.1" WB 8' Box	SuperCab 4x4 164.1" WB 8' Box	Crew Cab 4x2 159.7" WB 6.75' Box	Crew Cab 4x4 159.7" WB 6.75' Box	Crew Cab 4x2 175.9" WB 8' Box	Crew Cab 4x4 175.9" WB 8' Box
6.7L V8 Turbo Diesel	3.31	31,000*	23,100/23,800*	23,000/23,400,*	21,900/23,400*	21,600/23,000,*	21,700/23,400*	21,600/23,000,*	21,300/23,200*	20,900/22,800,*
6.7L V8 Turbo Diesel	3.55	31,000	23,100/23,800*	23,000/23,400,*	21,900/23,400*	21,600/23,000,*	21,700/23,400*	21,600/23,000,*	21,300/23,200*	20,900/22,800,*
6.7L V8 H.O. Turbo Diesel	3.31	31,800	23,100/24,600*	23,000/24,200,*	-	21,600/23,600/23,800*	-	21,600/23,600/23,800*	21,300/24,000*	20,900/23,600,*
6.7L V8 H.O. Turbo Diesel	3.55	31,200^†	-	-	-	-	-	23,000	-	-
6.7L V8 H.O. Turbo Diesel	3.55	35,200	23,100/25,900*	23,000/25,800/27,600*	21,900/24,600*	21,600/23,600/27,200*	-	21,600/23,600/27,000*	21,300/24,100*	20,900/23,600/26,700*
6.8L V8 Gas	3.73	21,000	14,600*	14,300/14,200,*	14,300/14,300*	13,900/13,900,*	14,300/14,300*	13,900/13,900,*	14,100/14,100*	13,700/13,700/13,600*
6.8L V8 Gas	4.3	24,400	18,000*	17,700/17,600,*	-	17,300/17,300,*	17,700/17,700*	-	17,500/17,500*	17,100/17,100/17,000*
7.3L V8 Gas	3.73	25,200	18,600*	18,300/18,300,*	-	17,900/17,900,*	18,300/18,300*	17,900/17,900,*	18,100/18,000*	17,700/17,700,*
7.3L V8 Gas	4.3	28,600^†	-	-	-	-	-	21,000	-	-
7.3L V8 Gas	4.3	29,000	22,400*	22,100/22,100,*	-	21,700/21,700,*	22,100/22,100*	21,700/21,700,*	21,900/21,800*	21,500/21,500,*
*18" All-Season Tires.
**18" and 20" All-Terrain Tires.
^†Tremor^®Off-Road Package.

F-350^®/F-450^® Super Duty DRW
Engine (Automatic Transmission)	Axle Ratio	GCWR (lbs.)	F-350^® Regular Cab 4x2 141.5" WB 8' Box	F-350^® Regular Cab 4x4 141.5" WB 8' Box	F-350^® Crew Cab 4x2 175.9" WB 8' Box	F-350^® Crew Cab 4x4 175.9" WB 8' Box	F-450^® Regular Cab 4x2 141.5" WB 8' Box	F-450^® Regular Cab 4x4 141.5" WB 8' Box	F-450^® Crew Cab 4x2 175.9" WB 8' Box	F-450^® Crew Cab 4x4 175.9" WB 8' Box
6.7L V8 Turbo Diesel	3.55	40,000	32,500	32,000	31,800	31,400	-	-	-	-
6.7L V8 Turbo Diesel	4.1	43,900	36,400	35,900	35,700	35,300	-	-	-	-
6.7L V8 Turbo Diesel	4.3	43,500	-	-	-	-	-	-	34,800	33,100
6.7L V8 Turbo Diesel	4.3	46,700	-	-	-	-	38,600	37,300
6.7L V8 H.O. Turbo Diesel	3.55	40,500	32,900	32,500	32,300	31,900	-	-	-	-
6.7L V8 H.O. Turbo Diesel	4.1	45,600	38,000	37,600	37,400	36,100	-	-	-	-
6.7L V8 H.O. Turbo Diesel	4.3	43,500	-	-	-	-	-	-	34,700	33,000
6.7L V8 H.O. Turbo Diesel	4.3	46,700	-	-	-	-	38,600	37,200	-	-
6.7L V8 H.O. Turbo Diesel	4.3	48,000**	-	-	-	-	40,000	-	-	-
6.8L V8 Gas	4.3	25,400	18,600/18,900*	18,200	-	17,600	-	-	-	-
7.3L V8 Gas	3.73	25,700	18,800	18,400	-	17,800	-	-	-	-
7.3L V8 Gas	4.3	29,500	22,500	22,200	-	21,600	-	-	-	-
*Heavy-Duty Payload Package.
**40k Gooseneck Tow Package.

Payload

		GVWR (lbs.)				Maximum Payload
F-250^® SRW Super Duty	Wheelbase	6.8L Gas	7.3L Gas	6.7L Diesel	6.7L H.O Diesel	6.8L Gas	7.3L Gas	6.7L Diesel	6.7L H.O Diesel
4x2 Regular Cab	141.5"	10,000	10,000	10,000	10,600*	4,240	4,246	3,473	3,903
4x2 Regular Cab	141.5"	-	-	10,600*	-	-	-	3,918	-
4x2 Regular Cab	141.5"	-	-	10,600	-	-	-	4,048	-
4x2 Super Cab	164.1"	10,000	-	10,000	11,000*	3,859	-	3,053	3,880
4x2 Super Cab	164.1"	-	-	10,600	-	-	-	3,625	-
4x2 Super Cab	164.1"	10,400	-	11,000*	-	4,234	-	3,896	-
4x2 Crew Cab	159.7"	10,000	10,000	10,000	10,800*	3,892	3,919	3,089	3,717
4x2 Crew Cab	159.7"	-	-	10,600	-	-	-	3,662	-
4x2 Crew Cab	159.7"	10,100	10,100	10,800*	-	3,968	3,995	3,732	-
4x2 Crew Cab	175.9"	10,000	10,000	10,000	11,100*	3,667	3,693	2,840	3,766
4x2 Crew Cab	175.9"	-	-	10,600	-	-	-	3,411	-
4x2 Crew Cab	175.9"	10,400	10,500	11,100*	-	4,042	4,068	3,781	-
4x4 Regular Cab	141.5"	10,000	10,000	10,000	11,000*	3,852	3,863	3,085	3,899
4x4 Regular Cab	141.5"	-	-	10,600	-	-	-	3,644	-
4x4 Regular Cab	141.5"	10,300	10,300	11,000*	-	4,115	4,126	3,914	-
4x4 Super Cab	164.1"	10,000	10,000	10,000	11,400*	3,482	3,494	2,706	3,918
4x4 Super Cab	164.1"	-	-	10,600	-	-	-	3,263	-
4x4 Super Cab	164.1"	10,600	10,600	11,200*	-	4,044	4,056	3,733	-
4x4 Crew Cab	159.7"	10,000	10,000	10,000	11,000**	3,546	3,572	2,757	3,384
4x4 Crew Cab	159.7"	-	10,300**	10,600	11,100*	-	3,424	3,314	3,669
4x4 Crew Cab	159.7"	10,500	10,500	11,100*	-	4,008	4,034	3,684	-
4x4 Crew Cab	175.9"	10,000	10,000	10,000	11,400*	3,240	3,266	2,430	3,640
4x4 Crew Cab	175.9"	-	-	10,600	-	-	-	2,985	-
4x4 Crew Cab	175.9"	10,600	10,600	11,200*	-	3,800	3,826	3,455	-

		GVWR (lbs.)				Maximum Payload
F-350^® SRW Super Duty	Wheelbase	6.8L Gas	7.3L Gas	6.7L Diesel	6.7L H.O Diesel	6.8L Gas	7.3L Gas	6.7L Diesel	6.7L H.O Diesel
17" Tires	-	-	-	-	-	-	-	-	-
4x2 Regular Cab	141.5"	-	-	10,600	10,600	-	-	3,948	3,933
4x4 Regular Cab	141.5"	10,400	10,400	11,000	11,000	4,137	3,992	3,923	3,908
4x2 Super Cab	164.1"	10,400	-	11,000	11,000	4,190	-	3,902	3,886
4x4 Super Cab	164.1"	10,800	10,800	11,300	11,300	4,201	3,985	3,829	3,798
4x2 Crew Cab	159.7"	10,200	10,200	10,800	-	3,987	3,769	3,718	-
4x4 Crew Cab	159.7"	10,600	10,600	11,200	11,200	3,994	3,778	3,717	3,702
4x2 Crew Cab	175.9"	10,600	10,600	11,100	11,100	4,167	3,951	3,777	3,793
4x4 Crew Cab	175.9"	10,900	10,900	11,499	11,499	4,056	3,880	3,765	3,750

18" All Seasonal Tires	-	-	-	-	-	-	-	-	-
4x2 Regular Cab	141.5"	10,500	10,500	11,100	11,100	4,608	4,391	4,389	4,374
4x4 Regular Cab	141.5"	10,900	10,900	11,499	11,499	4,578	4,433	4,363	4,348
4x2 Super Cab	164.1"	10,900	-	11,499	11,499	4,631	-	4,342	4,327
4x4 Super Cab	164.1"	11,300	11,300	11,499	11,499	4,642	4,426	3,969	3,938
4x2 Crew Cab	159.7"	10,600	10,700	11,300	-	4,328	4,211	4,159	-
4x4 Crew Cab	159.7"	11,000	11,000	11,499	11,499	4,335	4,219	3,957	3,942
4x2 Crew Cab	175.9"	11,100	11,100	11,499	11,499	4,609	4,392	4,117	4,133
4x4 Crew Cab	175.9"	11,300	11,300	12,000	12,000	4,398	4,221	4,207	4,192

18"/20" All Terrain Tires	-	-	-	-	-	-	-	-	-
4x4 Regular Cab	141.5"	11,400	11,400	12,000	12,000	5,073	4,928	4,859	4,844
4x4 Super Cab	164.1"	11,800	11,800	12,300	12,300	5,137	4,921	4,765	4,734
4x4 Crew Cab	159.7"	11,499	11,499	12,000	12,000	4,829	4,613	4,453	4,438
4x4 Crew Cab	159.7"	-	11,499**	-	12,000**	-	4,484	-	4,309
4x4 Crew Cab	175.9"	11,900	11,900	12,400	12,400	4,992	4,816	4,602	4,587

		GVWR (lbs.)				Maximum Payload
F-350^® DRW Super Duty	Wheelbase	6.8L Gas	7.3L Gas	6.7L Diesel	6.7L H.O Diesel	6.8L Gas	7.3L Gas	6.7L Diesel	6.7L H.O Diesel
4x2 Regular Cab	141.5"	14,000	14,000	14,000	14,000	7,744	7,635	6,952	6,935
4x2 Regular Cab	141.5"	14,000^†	-	-	-	8,000	-	-	-
4x4 Regular Cab	141.5"	14,000	14,000	14,000	14,000	7,340	7,203	6,519	6,504
4x2 Crew Cab	175.9"	14,000	14,000	14,000	14,000	-	-	6,275	6,261
4x4 Crew Cab	175.9"	14,000	14,000	14,000	14,000	6,706	6,599	5,865	5,850

		GVWR (lbs.)				Maximum Payload
F-450^® DRW Super Duty	Wheelbase	6.8L Gas	7.3L Gas	6.7L Diesel	6.7L H.O Diesel	6.8L Gas	7.3L Gas	6.7L Diesel	6.7L H.O Diesel
4x2 Regular Cab	141.5"	-	-	14,000	14,000	-	-	6,322	6,305
4x2 Regular Cab	141.5"	-	-	-	14,000^††	-	-	-	6,482
4x4 Regular Cab	141.5"	-	-	14,000	14,000	-	-	5,953	5,938
4x2 Crew Cab	175.9"	-	-	14,000	14,000	-	-	5,651	5,636
4x4 Crew Cab	175.9"	-	-	14,000	14,000	-	-	5,319	5,303
Payload capability will be reduced based on trim series, option content and passengers. See label on door jamb for carrying capacity of a specific vehicle.
*Requires Trailer Tow Package.
**Requires Tremor^® Off-Road Package.
^†Requires F-350^® Gas Heavy-Duty Payload Package.
^††Requires F-450^® High Capacity Gooseneck Tow Package.

SUVs & Cars

Capable, convenient, and versatile.

Trucks & Vans

Hauling, towing, and off-roading.

Electric & Hybrid

Performance Vehicles

Motorsports, Parts & Clubs

Commercial Vehicles

Ford Pro offers the tools, software and services to keep your business on track and crews on the road.

Future Vehicles

Moving ahead to move you.

2025 Super Duty® F-450® XL

Key Features

6.7L Power Stroke® V8 Turbo Diesel Engine

Integrated Box Side Steps and Rear Corner Bumper Steps

SYNC® 4 With 8-Inch LCD Touchscreen

Exterior Features

Appearance

Standard

Optional

Exterior

Optional

Protection

Standard

Optional

Windows & Glass

Standard

Optional

Interior Features

Climate

Standard

Optional

Comfort and Convenience

Standard

Optional

Entertainment Systems

Standard

Seating

Standard

Optional

Packages

Packages

Standard

Optional

Power and Handling

Handling

Standard

Optional

Power

Standard

Optional

Wheels & Tires

Standard

Safety

Safety

Standard

Security

Standard

Specifications

Highlights

Exterior

Interior

Capacities

Chassis

Engine

Towing

Payload

Build & Price

Request a Quote

2025 Super Duty^® F-450^® XL

6.7L Power Stroke^® V8 Turbo Diesel Engine

SYNC^® 4 With 8-Inch LCD Touchscreen
